18x18w RGBWA UV 6in1 LED Waterproof Par Light DJ Lights

Technical parameters:

Highlight

• New design par light products,with 18W super brightness LED
• Colorful: Red,Green,Blue,White,Amber and UV 6 color, Bring people in a colorful world.
• IP65 waterproof use Die cast aluminum body is good for rejection of heat and keep longtime use.
• Widely used in stage show, studio, theatre, outdoor wall of mansion etc.
• Controlled by DMX, master-slave, auto-running.

Product decription

18x18w RGBWA UV 6in1 LED Waterproof Par Light DJ Lights

Basic Knowledge

1) Electrical connections

Input voltage: ac90-245v / 50-60hz

Rated power: 180 (W)

Drive current: 4.5A

Power connection: power input and output

dmx connection: dmx input and dmx output

2) Optical system

Light source:18x10W( RGBWAUV 6 in 1) LED Rainbow effect

Light Angle:25degree,40degree (Optional 1)

Life time:10 0 000 h

3) Control mode

Control: DMX512 master-slave control, auto,sound, gradual change, Jump change

Channel: 6/9 channels (digital display)

Dimming: linear dimming effect (0-100% 16Bi dimming)

Function effect: shaking the display board to control static, custom mode, 0-25Hz strobe

4) Housing

Housing: die-cast aluminum

Color:black or white

Waterproof and dustproof mirror: tempered glass

IP:IP20

Lighting wide receiver: Power line in and out, dmx in and out

Cooling System: Die-cast high thermal conductivity

IP:IP20

Lighting wide receiver: Power line in ,dmx in and out

Cooling System: conductivity

Guangdong Jiale Electronics Co, Ltd having more than 14 years history, established in 2010, now is located in Lishui Town where enjoy the named by “Dream Water” in Nanhai District, Foshan, Guangdong, China, which has convenient transportation. Jiale now is a famous brand for its advance technology and trend design concept which is keeping abreast of the times, high quality and strong team of after service

Since it was set up, we insist With scientific and technological innovation, people-oriented for our develop idea. We also value talent team building, cultivate a group of top quality management staff, engineering and technical staff as well as well-trained workers team.

All the producing process and system are following the standard of modern business management, it contains impeccable quality test, monitoring, tracking and feedback systems all are working by the scientific management mode. In order to guarantee our products quality, we also set up whole quality control system and all our products are approve CE,ROHS,SGS international safety certificates

Our company main products are: Moving head series,High power LED Series,LED effect light,Exhibigion lighting etc. We will push forward stage light products combined with technology. Our products widely use in stage,booth,conference room,city bright project etc.


The products now are popular in America, Europe and other foreign countries, Jiale market is expanding constantly for its advanced design and excellent workmanship, as its high quality and effective service, we got highly regarded and identify by customers and show business.

We will develop new products in constantly and use new process, consistent and pay attention to product quality,after -sale service as well as company image. With our heart and soul to provide high-class service for different customers. Let us to conspire together the development, create the brilliancy together!
