Fireproof Velvet Cloth Rgb 3 In 1 Led Stage Vision Curtain Backdrop
DesignCurtain is an LED animation curtain with lower resolution.
But it still can show fantastic patterns. DesignCurtain uses super
bright RGB leds.
There are two control systems available for DesignCurtain.
JL-S950:This is a computer based controller. It has 8 data outputs,
each can drive 682 pixels, totally 5,456 pixels. With this
controller, users can freely edit patterns/flash, text, logos etc..
in EasyPlayer software, and display any media files as you like.
Users can set up EasyPlayer to do real time display of flash,
animation opened with any media player. To show any text, users can
type one line or multiple lines of text, and edit the text font,
size, color and movement direction and speed. If you are using a
large led curtain, you can also divide the big curtain into parts,
and each part displays different contents.
SD card controller: With the SD card controller, it can operate
with auto run mode, sound activation mode. Users can also control
the animation cloth with DMX desks. At DMX 512 mode, users can
select patterns in SD card, running speeds are also adjustable with
DMX desk.
Preset patterns can be edited with free software in computer and
stored in an SD card. Its controller can display up to 99 patterns,
one controller can control up to 6 pcs 6x4m curtains. In case users
need more than 6 curtains, controllers can be connected one to
another in serial. all curtains can be configurated (with free
software) to work as one larger curtains and show just one pattern
on the whole curtain. Patterns can be activated via all operation
modes. This curtain can also show texts or logoes (with bigger size
or higher resolution).
The curtain is made from heavy duty cloth . It is flame retardant,
easy to maintain. The curtain is finished with Velcro and grommets
at four sides, users can freely connect many curtains in any
configuration to creat a larger curtain.
This LED animation starcloth is designed for indoor applications.
It is really an indispensable tool for mobile DJs, stage, theatre,
TV studio, theme events, night club, hotel banqueting halls,
conference room, wedding etc.
Specifications
Electrical
Controller
Input voltage: 90-260V AC 50/60Hz
Power box
Input voltage: 90-260V AC 50/60Hz
Power supply: Switch power supply
Curtain power: Max. 1200W
Photometric
Light source: 2400 pcs ￠5 super bright RGB LEDs, higher density
available
LED lifetime: 80,000 hours
Effects
Buillt-in animation programs selectable via DMX desk or at auto run
mode
Users can edit up to 99 patterns in computer, and put in SD card
Auto run programs with speeds adjustable
Can display text and logo
Control
Control mode: Universal DMX512; Auto run; Sound activation, Or
computer based control for real time control.
Control panel: LCD display
DMX channel: 6 channels
DMX connector: 3-pin XLR input/output connector
Data output: CAT5 data output
Physical
Curtain material: Flame retardant heavy duty cloth
Curtain size: 6,000 x 4,000 mm
Curtain net weight: 28.5 kg
Curtain color: Black
Controller box size: 235L x 179W x 59H mm
Net weight: 1.2 kg
Controller color: Matt black
